Overview

CERMAX® XENON SHORT-ARC LAMPS

Operational Specifications
Description Nominal Range
Power 300 Watts 200-300 Watts
Current 21 amps (DC) 13-23 amps(DC)
Operating Voltage 12 Volts (DC) 11.5-15 Volts(DC)
Ignition Voltage 23 Kilovolts(system dependant)
Temperture 150℃ (Maximum)
Life Time 1000 hours typical
Initial Output at Nominal Power
F= UV Filtered Output
Description PE300C-10F/Y1830
Radiant Output* 75 Watts
UV Output* 9.7 Watts
IR Output* 34.5 Watts
Visible Output* 6725 Lumens
Color Temperature 5050° Kelvin
Peak Instabilities 4%
Spot Size at Focus 0.060”

* These values indicate total output in all directions. Wavelengths = UV<390 nm, IR>770 nm,
Visible: 390 nm-770 nm
* Nominal values at 300 watts after 2 hour burn-in.

Description Visible Output Total Output*
3 mm aperture 2300 Lumens 23 Watts
6 mm aperture 4500 Lumens 37 Watts

NOTES:

1. Lamp must not be operated with window facing upwards within 45° of vertical.
2. Seal temperature must not exceed 150°.
3. Current/power regulated power supplies and Excelitas lamp housing units are recommended.
4. Lamp must be operated within recommended current and power range. Over powering may lead to arc instability, hard starting and premature aging.
5. Hot mirror assembly is available for IR filtering.
6. Cermax® Xenon lamps are much safer lamps to use than their quartz xenon arc lamp equivalents. However, caution must be practiced when operating lamps because they are under high pressure, require high voltage, reach temperatures up to 200℃ , and their IR and UV radiation can cause skin burns and eye damage. Please read the Hazard Sheet included with each lamp shipment

Mechanical Dimensions:

dqwdwq1

Spectral Output:

bvfbfb2
